Cisco Linksys SPA3102 voice VOIP gateway with router

Prodam brezhiben praktično nerabljen Cisco Linksys SPA3102 zvočni VOIP prehod / voice gateway with router z navodili ter napajalnikom (Asterisk ipd.).

https://www.cisco.com/c/en/us/products/unified-communications/spa3102-voice-gateway-router/index.html

Description:

Telephony Features

• Service authentication via PIN, digest, and caller ID (Bellcore Type 1)

• Per-call authentication and associated routing

• Support for least-cost routing

• Impedance agnostics: eight settings

• Call waiting, cancel call waiting, call waiting caller ID detection (Bellcore Type 1)

• Caller ID with name and number (multinational variants)

• Caller ID blocking

• Call forwarding to PSTN or VoIP service: no answer, busy, all

• Do not disturb

• Call transfer

• Three-way conference calling with local mixing

• Message waiting indication - visual and tone based

• Call return

• Call back on busy

• Call blocking with toll restriction

• Delayed disconnect

• Distinctive ringing - calling and called number

• Off-hook warning tone

• Selective/anonymous call rejection

• Hot line and warm line calling

• Speed dialing of eight numbers/addresses

• Music on hold

• Fax: G.711 pass-through or real-time fax over IP via T.38

Product-Specific Features

• VoIP to PSTN (USA) service call origination and termination

• PSTN (USA) to VoIP service call origination and termination

• Single-stage and two-stage dialing

• Forward calls to VoIP service - selective, authenticated, all

• Forward calls to PSTN service - selective, authenticated, all

• PSTN line sharing with multiple extensions

• Automatic PSTN fallback (loss of power or IP service to unit - with quiescence to normal operations)

• Advanced inbound and outbound call routing

• Independent configurable dial plans - up to eight

• Force PSTN disconnection

• Sequential dialing support

VoIP to PSTN Authentication and Routing Features

• VoIP to PSTN gateway enable/disable

• VoIP caller authorization method (none, PIN, HTTP digest)

• VoIP PIN max retry setting

• One-stage dialing enable/disable

• VoIP caller ID pattern matching

• VoIP access allowed caller list (no further authentication)

• VoIP caller PIN and associated dial plan

PSTN to VoIP Authentication and Features

• PSTN to VoIP gateway enable/disable

• VoIP caller authorization method (none, PIN, HTTP digest)

• Ring through to FXS enable/disable

• Ring-through tone - configurable

• Caller ID (Bellcore Type 1) for VoIP service access

• Caller ID enable/disable

• PIN max retry settings

• Access allowed caller list (no further authentication)

• Caller PIN and associated dial plan

• Least-cost routing (via outbound VoIP - Line1 dial plan)

FXO Behavior Features

• VoIP answer delay timer

• PSTN answer delay timer

• VoIP PIN digit time-out timer

• PSTN PIN digit time-out timer

• PSTN to VoIP call max duration timer

• VoIP to PSTN call max duration timer

• PSTN ring-through delay timer

• PSTN dialing delay timer

• VoIP DIG refresh interval timer

• PSTN ring time-out timer

PSTN Disconnection Detection Features

• CPC (removal of tip/ring voltage momentarily)

• Polarity reversal

• Long silence (configurable time setting)

• Disconnect tone (such as reorder tone)

• Silence threshold

International Control Features

• FXO port impedance - configurable to 16 settings

• Ring frequency - configurable

• SPA to PSTN and PSTN to SPA gain settings

• Ring frequency - maximum setting

• Ring validation time setting

• Tip/ring voltage adjustment setting

• Ring indication delay setting

• Operational loop current minimum value

• Ring time-out setting

• On-hook speed setting

• Ringer impedance setting

• Line-in-use voltage setting

Robert, 064 143 007 (tudi Viber, WhatsApp, Telegram, Signal)
