Echo AudioFire 8 FireWire audio interface

Okrasite svojo studijsko opremo doma ali na poti z dvema univerzalnima vhodoma tega elegantnega vmesnika z mikrofonskimi predojačevalniki.

AudioFire8 ponuja enako visokokakovostno strojno in programsko opremo kot naš priljubljeni izdelek Layla3G, vendar z dodatkom FireWire vmesnika. Z AudioFire8 lahko snemate 24-bitni 96kHz zvok z nizko zakasnitvijo na katerem koli računalniku z operacijskim sistemom Windows XP/Vista ali Mac OS X (namiznem ali prenosnem) z vrati FireWire.

AudioFire8 je popoln center za vsak profesionalni studio, bodisi doma bodisi na poti. Ima 2 univerzalna vhoda z mikrofonskimi predojačevalniki, fantomskim napajanjem, vstavki kanalov in gumbi za nastavitev, tako da lahko preprosto priključite mikrofon ali instrument in snemate, kadar koli in kjer koli želite. AudioFire8 ima tudi 6 uravnoteženih analognih vhodov (TRS), 8 uravnoteženih analognih izhodov (TRS), stereo izhod za slušalke, 2 FireWire priključka, S/PDIF (koaksialni in optični) vhod/izhod, ADAT vhod/izhod, MIDI vhod/izhod, sinhronizacijo ure besedila in 16 kanalov polnega dupleksnega 24-bitnega 48kHz snemanja in predvajanja ali 12 kanalov polnega dupleksnega 24-bitnega 96kHz snemanja in predvajanja.

Hardware Specifications
FireWire (IEEE 1394a) interface with 15' cable

2 auto-sensing universal inputs (mic/guitar/line):
- Meters, trim knobs, phantom power, & channel inserts

6 balanced 1/4 in. analog inputs:
- 113dB (A-weighted) dynamic range
- +4dBu / -10dBV nominal levels

8 balanced 1/4 in. analog outputs:
- 114dB (A-weighted) dynamic range
- +4dBu / -10dBV nominal levels

2 unbalanced 1/4 in. channel inserts:
- +4dBu / -10dBV nominal levels

S/PDIF (coaxial and optical) I/O at 24-bit/96kHz

ADAT I/O

MIDI I/O

Stereo headphone output with volume knob

Sync via word clock, S/PDIF or ADAT

Supports full duplex 16 channel in, 16 channel out operation at 24 bit, 48 kHz sample rate or 12 channel in, 12 channel out operation at 24 bit, 96 kHz sample rate

Rack mountable single space interface box

Heavy-duty aluminum case

On-board DSP processing

Near zero latency hardware monitoring

Software console for monitoring, metering, and setting levels
Low-latency drivers support all major pro audio software:
- Low Latency ASIO 2.0
- WDM kernel streaming mode
- GSIF 2.0 (Gigastudio 3 w/ low latency MIDI) (Windows XP and Vista - 32-bit only)
- CoreAudio & CoreMIDI

System Requirements
PC System requirements:
- Windows XP or Vista (32 or 64 bit)
- 256 MB RAM (512 MB recommended)
- 400 Mbps FireWire port (IEEE 1394a)

Mac System Requirements:
- Mac OS X (10.4 or later)
- G4 or better processor
- 256 MB RAM (512 MB recommended)
- 400 Mbps FireWire port (IEEE 1394a)
